GPS Tracker with data download
TECHNICAL SPECIFICATION OF VEHICLE TRACKING DEVICE
|
Dimension | 60mmx85mmx30mm | Weight | 145g | ||||
Charging voltage | +9V – +35V / 1.5A | GPS Chipset | Latest GPS SIRF-Star III chipset | ||||
Back up battery | 550mAh lithium-ion battery | Operating temp | -20°C to 55°C | ||||
Humidity | 5%–95% | GPS Sensitivity | 158Db | ||||
LED indicator | 2 indicators show GSM/GPS status | GPS Frequency | L1, 1575.42 MHz | ||||
Channels | 20 channel all-in-view tracking | Interface | 2 input and 1 output | ||||
Velocity Accuracy | 0.1 m/s | Position Accuracy | 10 m, 2D RMS | ||||
Frequency | 850/900/1800/1900Mhz GSM | Time Accuracy | 1 us synchronized to GPS time |
ACCESSORIES |
GPS tracker OCT600 | 12V/24V relay | Power I/O cable | GPS Antenna | ||||
GSM Antenna | Udoc Kit |
OCT600-UD is a tracking device special for fleet company. It is helpful in long distance transportation. Data logging feature can store the data when the car is in the area without GSM network, and upload the server while network is recover. Server will give you a confirmation after all data transfer complete, to ensure no lost of data. And the key to offer a big help in fleet management is data download feature.You just need to go to the car, connect it with universal USB disk, and start downloading, the whole process just take a few sec. No need to remove tracker from the car.All data correction can be done in a short, and minimize the amount of time, reduce a lot of paper work.
Main Feature:
1. Real time tracking | 2. LBS Tracking | 3. Track by time/distance/degree/engine | 4.Google map link inquiry | ||||
5. Engine cut remotely | 6. SOS emergency alert | 7. Geo-fence alert | 8. Movement alert | ||||
9. Speeding alert | 10. External power cut alert | 11. Track by android APP | 12. Shaking alert | ||||
13. Data logging | 14. Data download by Udoc kit | 15. Speed limitation | 16. Vehicle info config and inquiry | ||||
17. Working time setting | 18. Engine detecting and alert | 19. SIM balance inquiry | 20. Fuel monitoring (option) | ||||
21. Mileage calculation & setting | 22. Miss call reminding for alarm | 23. Voice Monitoring (option) | 24. Vehicle maintenance reminding | ||||
25. 3 Admin No.s for management |
