Item Description Size 195mm x 114mm x 37mm Weight 1000g( Include main unit and 35CM Lock rope) Material Engineering plastic
Item |
Description |
Size |
195mm x 114mm x 37mm |
Weight |
1000g( Include main unit and 35CM Lock rope) |
Material |
Engineering plastic |
GPS Module |
Skylab 12BL |
GSM module |
Quectel M26 or UC15 or EC25 |
Working temperature |
-20°C -- +80°C |
Store temperature |
-40°C -- +80°C |
Humidity |
5%—99% |
Standard battery |
Rechargeable battery 10400mAh |
Average working current |
<90 mA |
Average current standby |
<100uA |
Working hour |
2G device(10400mAh) normal working mode: 100 hours |
|
3G device(10400mAh) normal working mode: 70 hours |
Waterproof |
IP67 |
Transmission mode |
Support TCP(GPRS) or SMS(short message) |
Main Functions |
Description |
Cellular network |
4G |
GPS+LBS Positioning |
LBS info.(CELL ID and LAC) |
Dual SIM cards |
It can be installed with two Micro SIM cards and supports the dual SIM single standby mode. The device will automatically select a SIM card to register the network. |
Long time Power |
Build in 10400mAH Rechargeable 18650 lithium battery |
Build in 3 Axis acceleration sensor |
Motion or vibration detecting |
Buzzer and LED indicators reminder |
Different device Status Buzzer and LED indicator reminder |
Charger |
5V DC -2A charging |
Bluetooth(Optional) |
Unlocking via APP or Download historical Track data through Bluetooth(replace serial port) |
Real time Position querying |
Query current location by SMS command |
Unlock by Password |
Unlock the device by Password(GPRS/SMS) |
Unlock device by authorized RFID key |
Unlock the device by authorized RFID keys |
Locked automatically |
The device will automatically lock when the lock rope is inserted |
50 authorized RFID keys |
Unlock the device by authorized RFID keys |
Polygon Geo-fence |
10 Polygon Geo-fences |
5 Authorized Phone Numbers |
Receiving short message alert or command response and sending command |
Supports 9 alerts |
Lock rope tamper, Swiping unauthorized RFID key, Unlocking, Wrong password, Vibration, Enter Geo-fence, Exit Geo-fence, Low battery, Back Cover Opened, Motor Fault |
Lock and Unlock Report |
The way to lock or unlock, unlock by Password or RFID key, report time, locked /unlocked successful or failed |
Wake up source |
Vibration, RFID Key Reading, Back Cover Opened, Lock rope inserted and unplugging, Sleep and timing wake up(RTC) |
GPS Platform with APP for both of Android and IOS |
Admin account for management. Free service. |
