ITEM

Technical Specifications

CPU

Dual-Core processor@1.5GHz,Total coding resources 1080p@60fps

NPU@1.0TOPS neural network acceleration engine

Memory

2Gb DDR3

Video Input

Active Pixels: 1920×1080,1080×720, H.264&H.265 format

2-ch Built-in CMOS camera

Configuration

Support mobile APP preview and setting

Audio input / output

Built-in MIC and speaker, G.711a format

Video recording resolution

2-ch 1080p*25fps,Simultaneous recording of sound and video.

G-Sensor

Built-in 3-axis acceleration

External interface

1-ch RS232, reserved for communication with peripherals

Alarm Input/output

1-ch SOS /1-ch Low output

Positioning module

GPS / Beidou Positioning Module

4G

built-in 4G module,TDD-LTE, FDD-LTE

WIFI

Optional support, 2.4G, 802.11b/g/n, AP mode

Storage

Support 1 TF card, Support 16G/32G/64G/128G/256GB/512GB

USB

Micro USB, support usb wifi dongle

Upgrade

TF card and OTA

AI - ADAS

Lane departure, collision alarm, Distance detection, pedestrian detection etc

AI - DSM

Fatigue driving detection, Smoking, call mobile phone, Occlusion, Unsafe driving behavior habit detection

Input voltage

DC:+10V ～ +36V

Power consumption

Normal working state ＜ 5W (without external equipment)

Power off protection

Super capacitor design, support abnormal power failure, ensure the integrity of video files

Working Temperature

-25℃ to +70℃

Working relative temperature

20% to 80%

Communication protocol

JT/T808-2011，JT/T808-2019，CMSV6

Equipment size

120mm*77mm*55mm

Net weight

240g
