ITEM

Technical Specifications

CPU

Dual-Core processor@1.5GHz,Total coding resources 1080p*100fps

NPU@1.0TOPS neural network acceleration engine

Memory

2Gb DDR3

Video Input

Active Pixels: 1920×1080,1080×720; H.264&H.265 format

1-ch Built-in CMOS camera, Low illumination 0.01LUX

3-ch External camera, AHD 720P@25fps

Video Output

Not support，Support mobile APP preview and setting

Audio input / output

Built-in MIC and speaker, G.711a format

Video recording resolution

1080P/720P/D1*25fps,Simultaneous recording of sound and video.

G-Sensor

Built-in 3-axis acceleration

External interface

2-ch RS232, reserved for communication with peripherals

Alarm Input

2-ch sensor input,

Positioning module

Built-in GPS / Beidou Positioning Module

4G

built-in 4G module,TDD-LTE, FDD-LTE

WIFI

Built-in, 2.4G,802.11b/g/n,STA or AP mode

TF Card

Support 1 TF card, Support 16G/32G/64G/128G/256GB/512GB

USB

Micro USB interface

Upgrade

TF card and OTA

AI - ADAS

Lane departure, collision alarm, Distance detection, pedestrian detection etc

AI - DSM

Fatigue driving detection, Smoking, call mobile phone, Occlusion, Unsafe driving behavior habit detection

AI - BSD

Blind area detection

Input voltage

DC:+10V ～ +36V

Power consumption

Normal working state ＜ 5W (without external equipment)

Power off protection

Super capacitor design, support abnormal power failure, ensure the integrity of video files

Working Temperature

-25℃ to +70℃

Working relative temperature

20% to 80%

Equipment size

138mm*85mm*45mm

Net weight

0.3kg
